1. Main parameters of electrogalvanizing production line.
| No | Item | Specification |
| 1 | material | steel wire |
| 2 | wire diameter range | φ0.45~φ3.5 mm |
| 3 | coating type | zinc |
| 4 | coating weight | 5~60g/m2 |
| 5 | wire lines | 36,48 or 56 lines |
| 6 | speed(DV) | DV=75 or 95m*mm/min(max speed 70 or 90m/min) |
| 7 | fuel type | NG or LPG |
2. Technological process of production.
Pay off→Degreasing→Heat treatment→Patenting→Water
cooling→Pickling→Water rinsing→Zinc plating→Water rinsing→Hot water
rinsing→Drying→Take up
3. Main process introduction.
Degreasing: remove the uneven soap powder and borax, and paint a layer of
soap powder and borax on the surface of bright steel wire, so that
the surface coating of steel wire is more uniform.
Heat treatment: make the deformation hardening steel wire to restore the
ductility, and obtain the ideal microstructure to meet the cost of
steel wire in tensile strength, shape, elongation and other
requirements.
Patenting: the heat-treated steel wire is cooled down from high temperature,
and the water vapor quenching process is used to obtain strong
strength and shaped sostenitic structure.
Pickling: remove all oxides and residues on the surface of the steel wire,
and the clean surface is conducive to uniform coverage of the rear
coating.
Zinc plating: deposition of metal zinc on the surface of steel wire.
4.Product application
1, Construction field
Galvanized steel wire is widely used in the construction field,
mainly for the reinforcement of guardrails, grid structures, and
reinforced concrete components in buildings. The galvanized steel
wire material is sturdy and durable, and after galvanizing
treatment, it is not easy to rust and corrode, which can extend the
service life of buildings.
2, Agricultural sector
Galvanized steel wire in the agricultural field is mainly used for
support and fixation in horticulture, orchards, grape racks, and
other places, and can also be used for making facilities such as
livestock pens and poultry houses. Due to its high material
strength and good corrosion resistance, it can adapt to various
complex environments and blend harmoniously with the surrounding
environment.
3, Transportation sector
In the field of transportation, galvanized steel wire is commonly
used in facilities such as highway guardrails, bridge protective
railings, and vehicle barriers. Galvanized steel wire is mainly due
to its high strength, good corrosion resistance, adaptability to
complex environments, and ability to effectively improve the
service life of facilities.
4, Landscape aquaculture field
In the field of landscaping and aquaculture, galvanized steel wire
is often used to make animal and plant protection fences, garden
guardrails, rattan racks, bird cages, aquaculture cages, deep
aquatic troughs, net cages, etc. Due to its excellent
anti-corrosion performance and resistance to external forces,
galvanized steel wire is very suitable for use in outdoor
environments.
In short, galvanized steel wire is a type of steel wire product
that has undergone galvanizing treatment, with characteristics such
as good anti-corrosion performance, high strength, and strong
durability. It has been widely used in various fields such as
construction, agriculture, transportation, landscaping, and
aquaculture.
5. Our Services
In order to guarantee the customers are able fully to operate the
machine, if the customer need, we can help customer training,
includes:
(1) Correct operating mode
(2) Correct maintenance way
(3) Correct technological process control
(4) Remove simple problem
All the electroplating machine of our company have already been
widely used in electroplating area.
Any doubt please contact us.
